POR01, POR02, & POR03

Portland Data Centers

Empower Your Edge in Portland, OR

The Portland Edge Data Center® (EDC) campus houses two purpose-built, Tier-3 designed facilities, with an additional facility planned, all with superior operational reliability to support cloud, content, network and enterprise customers.

AWS Direct Connect, Azure ExpressRoute, and Google Cloud Interconnect cloud on-ramps for direct access to these major cloud services are available locally in our Portland facilities, along with other cloud solutions for enterprises offered through our technology and solution partners.

In addition to AWS, Azure, and Google, customers can access leading CSP’s like Microsoft, Oracle, Salesforce, Nutanix, IBM, and more. At EdgeConneX, we work with our customers throughout the full life-cycle, to deliver capacity, connectivity, and visibility, wherever and whenever they need it. Learn more.

Learn more about Portland in this trends feature: Power Up in Portland

Download Data Sheet Request a Virtual Tour Capacity Quote
background pattern

At a Glance

Facts and figures you need to know about our Portland, OR data centers.

POR01 18,700 sq ft of raised floor for tenant racks
POR02 16,850 sq ft facility
Direct Cloud Services access available
Located 14 Miles from downtown Portland

Leading Network Providers

Our Portland data centers offer a strong mix of leading NSPs, ISPs, and IXs to help you meet all your connectivity requirements. Whether you need to connect locally, within the region, or even globally, we have the right networking solution available to fit your needs.

Portland carrier logos



Specifications

  • Space

    • POR01:
      • 39,400 sq ft facility
      • 18,700 sq ft of raised floor for tenant racks
    • POR02:
      • 2 data halls totaling 16,850 sf
      • Phase 1 Data Hall: 8,300 sf
      • Planned Data Hall 2: 8,550 sf
    • POR03:
      • Planned addition to data center campus
    • Within 14 miles from downtown Portland
    • 27 miles from PDX Portland International Airport
    • Customer work space available
    • Space available for secure customer storage
    • WiFi network access and cellphone repeaters/boosters throughout the facility
  • Power

    • POR01:
      • Capable of 20+kW per cabinet
      • Capable of 600+ watts per sq ft
    • POR02:
      • Initial capacity 3MW N+1; planned for 6MW N+1 total
      • Capable of 30+kW per cabinet
    • POR03:
      • Up to 21MW planned
    • Concurrently maintainable power in a minimum of an N+1 configuration to include:
      • PDU
      • UPS
      • Generators
    • Ghost space not required for cooling power dense installations
    • Real-time branch circuit monitoring
  • Cooling

    • Temperature and humidity monitored, controlled and managed to industry standards
    • 30 inch raised/under floor forced air plenum
    • N+1 CRACs located in separate suites, maximizing customer-designated areas
  • Security

    • Multi-stage security containment systems that use PIN and live video authentication
    • Mantraps and strictly enforced protocols regarding entry access
    • 24/7 Color CCTV/video surveillance and >90-day online video storage
    • Interior managed security zones
    • National network operations center for security management
    • 24/7 NOC services
  • Network

    • Building POEs are diverse, with a variety of fiber conduits to physically diverse MMR’s
    • Leading NSP’s and MSO’s are deployed and available, providing direct access to AWS Direct Connect, Microsoft Azure ExpressRoute, and Google Cloud locally in our facility.
    • In addition, we offer solutions from SDN and IX partners like Megaport, PacketFabric, NetFoundry, and NWAX
    • Arelion, Astound, Bandwidth IG, Charter, City of Hillsboro, City of Sherwood, CloudFlare, Cogent, Comcast, Hunter Communications, Hurricane Electric, Lumen, Megaport, NWAX, PacketFabric, Tata, Uprise Fiber, Verizon, WhiteSky, Wholesail, Zayo, Ziplys
    • Interconnection services available
  • Fire Suppression

    • Pre-action, zoned dry-pipe sprinkler systems with zoned maintenance aisles and separate suites
  • Optional Services

    • Remote hands services for break fixes, configuration and troubleshooting
    • EdgeConneX Services: design, build, implement and maintain your equipment infrastructure
    • HIPAA, SOC 2 Type 2, PCI-DSS, ISO 27001 compliant
      PCI-DSS compliance logo SOC compliance logo ISO 27001 compliance logo HIPAA compliance logo
  • EdgeOS

    EdgeOS, our next generation data center operating system, provides real-time visibility including ticketing and SLA management for all EdgeConneX locations
